Unit Description (18-0015) AM-48 Test Set
0015-S033-14
Note: Switch 3 and Switch 14 control the speaker/
earphone monitoring point. See Figure 9-1 for a
block diagram showing the interaction of these
switches. When Switch 3 is set to <DAMP>, the
monitor point is after the auto-range amplifier,
which significantly increases the speaker level.
WARNING
For a given volume setting, the earphone audio level
sounds much higher than the speaker level. Be careful
to adjust the audio volume down before inserting the
earphone into the ear.
3.6 Keyboard
See Figure 3-6 for the AM-48 keyboard with identification numbers
which are referenced in the descriptions of this paragraph.
Auxiliary Functions . The AM-48 is equipped with auxiliary keypad
functions which are identified in Figure 3-6 with reference numbers 2
thru 9. The keys and their auxiliary functions are:
[*] START
[#] STOP
[A] ETR/NEXT
[B] ETR/PREV
[C] CANCEL
[D] ±
Note: To enable the auxiliary functions, set Switch 7 to <SHIFT>.
