2. Note the color-coding and framing of the cursor menus and use
these to determine if a filter is needed (orange functions) or a
holding tone is needed (within the rectangle) for the present
position of the cursors. See ¶3.7 and 7.23 for explanation of
menu framing.
3. Note the setting of Switch 2, the Display Select Switch. This
will indicate what is being viewed on the display. <ABS> or
<REL> indicate that the display is viewing the MEASURE mode;
while <SEND> indicates the display is viewing the SEND mode.
4. Note the setting of Switch 7. This indicates whether the
keyboard is connected to dial (<DTMF> or <MF>) or to operate
the auxiliary functions (<SHIFT>).
7.4 Figure Format
Figures 7-1 thru 7-9 show the display(s) which can be accessed from
the indicated SEND or MEASURE mode. The position of the menu
cursor, the necessary switch settings, and other pertinent information
is indicated in each figure. A detailed description of the arrangement
of the figures is listed below.
1. The
display fields are shown with three (3) types of characters.
The characters are illustrated at the bottom of some figures in a
table labeled “DISPLAY CHARACTER CODE”. The meanings of
the characters are:
a)
Solid : These letters and numbers are fixed and will
always appear just as they are shown. They are
abbreviations for the names of the parameters.
