05/05 Line1_flg
What is displayed on line 1 of the display
0 – blank line
2 – oxygen
4 – cell temperature
6 – cell mv
8 – thermocouple mv
10 – box temp
IQ
12 – combustibles
14 – methane
16 – methane and combustibles
18 – combustible voltages
IQ
20 – methane voltages
IQ
22 – time and date
24 – user text
S2
AF Ratio
IQ
26 – WOBBE
IQ
R/W
06/06 Line2_flg
What is displayed on line 2 of the display
0 – blank line
2 – oxygen
4 – cell temperature
6 – cell mv
8 – thermocouple mv
10 – box temp
IQ
12 – combustibles
14 – methane
16 – methane and combustibles
18 – combustible voltages
IQ
20 – methane voltages
IQ
22 – time and date
24 - user text
S2
AF Ratio
IQ
26 - WOBBE
IQ
R/W
07/07 Line3_flg
What is displayed on line 3 of the display
0 – blank line
2 – oxygen
4 – cell temperature
6 – cell mv
8 – thermocouple mv
10 – box temp
IQ
12 – combustibles
14 – methane
16 – methane and combustibles
18 – combustible voltages
IQ
20 – methane voltages
IQ
22 – time and date
24 - user text
S2
AF Ratio
IQ
26 – WOBBE
IQ
R/W
08/08 Oxygen The oxygen reading in percent Read only
09/09 Cmbcomb The combustibles reading Read only
0A/10 Mthcomb The methane reading Read only
0B/11 Cell_temp The current cell temperature in degrees C Read only
0C/12 Cell_mv The cell millivolts Read only
0D/13 Tc_mv The thermocouple millivolts Read only
