Serial Communications
| A-11
Iout_flags
S2
Analog outputs flags (1=true, 0=false)
bit 0 – analog output 3 tracks during
calibration
0 is hold analog output 3 during
calibration
bit 1 – analog output 3 tracks during
verify
0 is hold analog output 3 during verify.
bit 2 – analog output 3 set for 0 to 20 ma,
0 is 4 to 20 ma
bit 3 – Future use
bit 4 – analog output 4 tracks during
calibration
0 is hold analog output 4 during
calibration.
bit 5 – analog output 4 tracks during
verify
0 is hold analog output 4 during verify.
bit 6 – analog output 4 set for 0 to 20 ma,
0 is 4 to 20 ma
bit 7 – Future use
bit 8 – analog output 1 tracks during
calibration
0 is hold analog output 1 during
calibration
bit 9 – analog output 1 tracks during
verify
0 is hold analog output during verify.
bit 10 – Analog output 1 is set to 0-20, 0=
Output 1 is set to 4-20ma
bit 11 – Future use
bit 12 – analog output 2 tracks during
calibration
0 is hold analog output 2 during
calibration
bit 13 – analog output 2 tracks during
verify
0 is hold analog output during verify.
bit 14 – analog output 2 set for 0 to 20
ma, 0 is 4 to 20 ma.
bit 15 – Future use
R/W
04/04 Probe_type 0 – Insitu
IQ
1 – Cem/02
IQ
2 – WDG
IQ
3 – HP
IQ
4 – EI 20
IQ
5 – SA/F
IQ
A – Insitu
S2
B – CEM/O2
S2
C – WDG
S2
D – HP
S2
E – TM
S2
F – 3-in-1
S2
R/W
