03/03 Iout_flags
IQ
Analog outputs flags (1=true, 0=false)
bit 0 – analog output 1 tracks during
calibration
0 is hold analog output 1 during
calibration
bit 1 – analog output 1 tracks during
verify
0 is hold analog output during verify.
bit 2 – Future use
(used on S2000)
bit 3 – Future use
bit 4 – analog output 2 tracks during
calibration
0 is hold analog output 2 during
calibration
bit 5 – analog output 2 tracks during
verify
0 is hold analog output during verify.
bit 6 – analog output 2 set for 0 to 20 ma,
0 is 4 to 20 ma.
bit 7 – Future use
bit 8 – analog output 3 tracks during
calibration
0 is hold analog output 3 during
calibration
bit 9 – analog output 3 tracks during
verify
0 is hold analog output 3 during verify.
bit 10 – analog output 3 set for 0 to 20
ma, 0 is 4 to 20 ma
bit 11 – Future use
bit 12 – analog output 4 tracks during
calibration
0 is hold analog output 4 during
calibration.
bit 13 – analog output 4 tracks during
verify
0 is hold analog output 4 during verify.
bit 14 – analog output 4 set for 0 to 20
ma, 0 is 4 to 20 ma
bit 15 – Future use
R/W
