Ametek Thermox Series 2000 WDG-IVC User Manual

B-2 | Thermox Series 2000 WDG-IV / IVC / IVCM
ALARM KEY
Menu Options
Functions/Options
Alarm Set Points Alarm 3 Value
Alarm 4 Value
Alarm 5 Value
Alarm 6 Value
Alarm 7 Value
Alarm 8 Value
Alarm Congure
(for Alarms 3 and 4)
High O2
Low O2
Relay Congure Energize on Alarm
De-energize on Alarm
Select Function
( Alarm 3)
% Oxygen
Start of Calibration
Start of Verify
Start of Calibration or Verify
Exception Log N/A
Table B-3. Alarm Key menu.
ALARM NUMBER
FUNCTION
*Select Function Alarm Congure Relay Congure
Alarm 3 % O
2
Cal Start
Verify Start
Cal/Verify Start
High O
2
Alarm
Low O
2
Alarm
Energize on alarm
De-energize on alarm
Alarm 4 Not selectable
(% O
2
only)
Alarm 5
Not selectable
(combustibles only)
Not Selectable
(high alarms only)
(Disabled during
calibration cycle)
Alarm 6
Alarm 7
Not selectable
(methane only)
Alarm 8
* Note: Alarms 1 and 2 are reserved for the watchdog timer and service alarms and are
not software-selectable.
Table B-4. Alarm Set Point sub-menu.
