Anderson Group Self-loading Bale Carrier TSR-3450 Operator's Manual 27
4 Adjustments
In order to effectively handle various bale sizes, you must make certain adjustments.
You must make the adjustments BEFORE start-
ing to load bales.
Here are the adjustments to make, depending on the bales length, width, height, and weight:
Bale Length
l Grabber Travel Limit
l Bale Guide
Bale Width
l Grabber Width
l Pusher Frame Stroke
Bale Height
l Scissor Platform Height
l Loading Arm Position
l Barrier Height
l Pusher Frame Height
Bale Weight
l Counterweight Use
4.1 Grabber Travel Limit
Loading arm grabber depth is adjusted based on the length of the bales being handled. This
provides for correctly centring the bales on the carrier. In order to modify the grabber depth, simply
change the position of its travel limit as follows:
1. With a wrench, remove the bolts holding the travel limit in its current position in its two posts
(A).
2. Slide the travel limit towards the front or back depending on the desired position.
3. Replace the bolts to hold the travel limit in place.
