Anderson Group Self-loading Bale Carrier TSR-3450 – Operator's Manual 41
Ensure that the pusher frame height adjust-
ment is the same as for the scissor platforms.
Figure 18– Pusher Frame Height Adjustment
4.9 Counterweight Use
As shown in Figure 19 – Counterweights, the self-loading bale carrier is equipped with coun-
terweights (A) opposite the loading arm. These counterweights are used to counterbalance the bale
weight. A holder (B) is also provided to add additional counterweights, if needed. This holder may
house several counterweight models generally used on tractors. These counterweights are not
included with the bale carrier.
