44 Operator's Manual – Self-loading Bale Carrier TSR-3450 Anderson Group
Button/Action Manoeuvre
D Pivot the grabber towards the ground
E Open the grabber
F Close the grabber
G Move the pusher frame to the rear
H Return the pusher frame to the front (if necessary)
5.2 Bale Loading
The TSR-3450 carrier collects bales in the direction the bailer placed them on the ground.
When using the bale carrier, the loading arm
should never touch the ground. This could dam-
age it or cause an accident.
In order to load bales, proceed as follows:
1. Lower the loading arm to the bottom and open the grabber.
NOTE: If your bale carrier is perfectly parallel to the ground,
the grabber should not touch the ground.
Bottom Bale
2. Align the grabber such that the two arms are on either side of the bale and move forward.
