Anderson Group Self-loading Bale Carrier TSR-3450 – Operator's Manual 31
4.4 Pusher Frame Stroke
The pusher frame stroke represents the distance the push frame travels to push the bales towards
the rear of the carrier and free up space for new bales. So, the pusher frame stroke must be adjus-
ted based on bale width. This adjustment must also correspond to the grabber width adjustment. In
order to adjust the pusher frame stroke, place the travel limit on the appropriate post, as per the
indications in the following table.
Figure 9– Pusher Frame Travel Limit
Table 3– Travel Limit Position Based on Bale Width
Position Bale Width
A More than 1 m (40 in)
B 1 m (40 in) and under
