Anderson Group Self-loading Bale Carrier TSR-3450 – Operator's Manual 53
Table 8- Lubrication
Frequency Part (number of lubricating points)
Every 10 hours use Wrist cylinder articulations (2)
Loading arm cylinder articulations (2)
Every 50 hours use Tandem axle pivots (2)
Unloading platform pivots (2)
Unloading platform cylinder articulations (4)
Drawbar (1)
As needed Jack (1)
No lubrication is necessary on the loading arm
pivots, wrist, and scissor platforms.
Figure 30- Wrist Cylinder Articulations
