ML248xA / ML249xA Assembly and Connections
3-4 13000-00162
September 2005
Single Unit Rack Mounting (Option 01)
This section describes the assembly procedure for fitting a single ML248xA / ML249xA
into an instrument rack. The universal top and bottom covers have removable feet to
allow the rack mount kit to be fitted. The procedure involves fitting the support bracket,
front plate, base panel, and a rear support bracket to the ML248xA / ML249xA. The
ML248xA / ML249xA can then be loaded and secured in the rack position.
Kit Parts List
Anritsu No. Description Quantity Max Torque
Setting
50077 Front face plate 1
900-848 M4, kep nut. 2 14 lbf.in [158
cNm]
790-319 Speed nut 4
900-345 #4, sst, washer, flat 8
900-821 Decorative screw 4
905-68 M3x8, pos, sst, patchlock,
screw, metric, pan head.
8 4 lbf.in [45 cNm]
788-575 Snap rivet, plastic 6
C37276 Rack mount, side, bracket 1
C41449 Rear support, bracket, rack
mount
1
D41473 Rack mount, support bracket 1
49361 Bracket support, base panel 1
ML248xA /
ML249xA
Fitted with universal top and
bottom covers with removable
feet.
1
50210 Foot removal tool 1
Tools Required
1 Small Phillips screwdriver
1 Large Phillips screwdriver
1 Small Phillips torque screwdriver 0 cNm to 50 cNm
1 Torque socket driver 10 cNm to 120 cNm
1 Foot removal tool (supplied)
1 Assembly drawing “ML248xA/01 Rack Mounted left or right option”
