Assembly and Connections ML248xA / ML249xA
13000-00162 3-5
September 2005
Assembly Procedure
1. Confirm the correct tools are available, the parts listed above are present and the
assembly drawing is at hand.
2. Remove all feet from the ML248xA / ML249xA using the tool supplied. See diagram
and notes on the following pages.
3. Lay the large support bracket D41473 next to the ML248xA / ML249xA as per the
assembly drawing. If the instrument needs to be mounted on the left side of the rack,
lay the bracket on the right side. i.e. a mirror image of the assembly drawing.
4. Locate the support bracket on to the four case pillars. Secure with 4 screws 905-68
and 4 washers 900-345. See max. torque setting above. Leave the two rear screws
loose to allow alignment, location, and securing of the 6 base plate snap rivets 788-
575.
5. Locate the front rack mounting bracket C37276 at the front of the instrument on the
other side to the large support bracket with two screws 905-68 and two washers 900-
345. See max. torque setting above.
6. Locate the rear rack bracket C41449 at the back of the instrument on the other side
to the large support bracket with two screws 905-68 and two washers 900-345. See
max. torque setting above.
7. Fit the front face plate 50077 with 2 kep nuts 900-848. See max. torque setting
above.
8. Position the base panel 49361 as shown in the drawing, and secure with 6 snap
rivets 788-575.
9. Fit the four speed nuts 790-319 to the rack in the correct place to allow mounting of
the instrument in the rack.
10. Slide the instrument into the rack and secure with 4 decorative screws 900-821.
