13000-00162 B-1
September 2005
Appendix B. Specification
Specifications
Frequency Range 100 kHz to 65 GHz, sensor dependant
Power Sensors Meter compatible with all MA2400A/B/C/D Sensors
Display Measurement Range -70 to +200dBm dependant upon sensor range, external coupler or attenuator
Display Resolution Selectable from 0.1 to 0.001 dB in Readout Mode
0.01dB in profile mode
Time Axis
1ns settable resolution Pulse/Modulated Mode <200ns capture time (200 points)
15us CW Mode
Display Units Linear: nW to GW,%,Volts
Log: dBm,dBW,dB, dBµV,dBmV
Measurements Power:-Average, Peak, Crest, Maximum, Minimum
Statistics:- PDF, CDF and CCDF
PAE:- Power Added Efficiency
Measurement Modes Pulse/Modulated for wideband measurements
CW for CW measurements
Peaking Meter ±5dB range Readout/CW mode only
Measurement Display Profile (Graph) for Pulse/Modulated Mode
Readout (Numerical) for Pulse/Modulated and CW
Display Average, Max, Min, Max and Min
Measurement Hold, Max, Min Hold
Power Measurement Dynamic Range
Overall Dynamic Range Standard Diode Sensors:
-70 dBm to +20 dBm CW mode
-34dBm to +20dBm Pulse Modulated Mode
Wideband Sensors:
-60 dBm to +20 dBm CW mode
