Assembly and Connections ML248xA / ML249xA
13000-00162 3-9
September 2005
Tools Required
• 1 Small Phillips screw driver
• 1 Large Phillips screw driver
• 1 Small Phillips torque screwdriver 10 cNm to 120 cNm
• 1 Foot removal tool 50210 (supplied)
• 1 Assembly drawing “ML2480/03 SIDE BY SIDE OPTION”
Assembly Procedure
1. Confirm the correct tools are available, the parts listed above are present and the
assembly drawing is at hand.
2. Remove all feet using the tool supplied. See diagram on the following page.
3. On the two sides of the ML248xA / ML249xA to be joined together, fit the two rear
brackets 49413, C37279, and two front brackets C37275, C37277 using 8 screws
905-68 and 8 washers 900-345. See max. torque setting above.
4. Slide the two units together and secure using 4 counter sink screws 905-69.
5. Locate the two front rack brackets C37276 and 49415 at the front of each unit, one
on each side with four screws 905-68 and four washers 900-345. See max. torque
setting above.
6. Locate the two rear rack brackets C41449 at the back of each unit, one on each side
with four screws 905-68 and four washers 900-345. See max. torque setting above.
7. Fit the four speed nuts 790-319 to the rack in the correct place to allow mounting of
the two units in the rack.
8. Slide the two units into the rack and secure with 4 decorative screws 900-821.
