Anritsu ML2480B Series User Manual

Common Procedures ML248xA / ML249xA
13000-00162 5-21
September 2005
Entering the Settling Percentage
The settling value allows some control over the tradeoff between speed and the extent to
which a measurement has settled to its final value. A 1% settling time value relates to
approximately 0.04 dB.
1. Press the Channel hard key to display the Channel group of commands.
2. Press the Set Up soft key to display the [Channel Set Up] dialog for the channel that
is currently active.
3. Press the down arrow on the numerical keypad to select “Settling %”.
4. Press the [Sel] key and enter the required setting value from the numeric keypad.
5. Press the Enter soft key when complete.
6. Use the arrows on the numerical keypad to select another item in the dialog, or press
the [Exit] hard key if no further settings are required.
Note: The “Settling %” item is only available in CW mode.
