ML248xA / ML249xA Common Procedures
5-48 13000-00162
September 2005
3. Use the arrows on the keypad to select the marker, and then enter the required
position using either of the methods detailed below.
• Use the Inc and Dec soft keys to increment or decrement the displayed value.
• Press the [Sel] key on the keypad and enter the number in the usual manner.
4. Once the position has been set the user can chose to display the marker by pressing
Display Marker . The LED to the left of the input value is lit green when the marker is
set to be displayed.
5. Use the down arrow on the numeric keypad to move to the remaining markers, and
repeat steps 3 and 4 above.
6. Press [Exit] to close the [Marker Set Up] dialog when all settings are complete.
Turning all Markers Off
1. Press the Channel hard key followed by the Markers soft key to display the [Markers]
group of commands.
2. Press the Set Up Markers soft key to display the [Marker Set Up] dialog.
3. Press the All Mkrs Off soft key to clear all markers from the display.
