ML248xA / ML249xA Common Procedures
5-80 13000-00162
September 2005
Editing Cal Factor Tables
This section explains how to edit or create cal factor tables as mentioned in the section
titled,
Setting the Calibration Factor Applied to the Sensor earlier in this chapter.
1. Press the Sensor hard key followed by the Edit Tables and Edit CF Table soft keys
to display the [Edit Cal Factor Table] dialog.
2. The table number is indicated in the top right hand corner of the dialog. If the table is
not correct, press the Select Table.. soft key and enter the required table number
from the keypad in the normal manner.
3. Press the Edit Entries soft key to highlight the upper left cell in the table. Use the
arrow keys on the keypad to select the cell to be changed, press [Sel] and enter a
new value in the normal manner. The soft keys that display when the [Edit Cal
Factor Table] is open allow the user to navigate between cells and page the list up
and down.
Note: To clear a table completely, press Table Init followed by Clear Table . All data in
the table is cleared except for the first line. The Preset Table command that also displays
on this page can be used to set the table in question to the factory default setting.
4. When editing is complete, press [Back] and then press the Save Table soft key to
save the changes made.
