SECTION 3 PANEL DESCRIPTION
3-5
No. Panel Marking Explanation of Function
14 Entry These keys set the numeric data, units and special functions.
[Rotary knob] Used for moving marker and inputting data.
[ , ] Increments and decrements input data.
[Shift] To execute panel functions indicated by blue letters,
press this key and then press the blue-lettered key.
[BS] Backspace key for correcting input mistakes.
[0-9, . , +/–] Numeric-data setting keys.
[GHz, MHz, kHz, Hz]
Units keys for frequency, level, time, etc.
15 Preset This sets the measurement parameters to the default values.
16 Local This changes the remote status to the local status.
17 Copy This outputs a hard copy of the screen to a printer or plotter.
18 Stby/On This is the power switch. It can be used when the back-panel power
switch is on. The power-on condition is fetched from the Stby condition
when the key is pressed for about 1 seconds. The equipment is returned
to the Stby condition from the power-on condition when the key is
pressed again for about 1 second.
19 Memory Card This is the slot to set memory cards which save/load the waveform data
and measurement parameters etc. Up to two plug-in memory card can be
used.
20 RF Input This is the RF input connector.
21 Local Output This is the output connector for external mixer local drive signal and
input connector for if signal of external mixer.
In case of MS2665C, this connector is not provided.
50 (Fan) This is the cooling fan for ventilating internally-generated heat. Leave a
clearance of at least 10 cm around the fan.
51 10 MHz STD They are the input connector for an external reference crystal oscillator
and the output connector of the 10 MHz Reference signal. When an
external reference signal is input, the equipment switches automatically
from the internal signal to the external signal.
In case of MS2665C, if Option 01 is not attached to, this connector is not
provided.
52 IF OUT This is the IF output connector. This signal is bandwidth controlled by
the RBW setting.
To Next Page
