SECTION 4 SOFT-KEY MENU
4-10
RBW
VBW
Atten
Swee
Time
Manual
All Auto
RB,VB,SWT
Auto
RBW
Auto
Ratio
RB/Span
On Off
Ratio
RB/Span
0.01
MS2665C Menu Tree (3/25)
Panel Key
Top menu Lower menues
Manual
Auto
RB,VB,SWT
All Auto
All Auto
Sweep Time
Manual
Auto
All Auto
Attenuator
#1
Manual
All Auto
RB,VB,SWT
Auto
VBW
Auto
Filter
Off
Ratio
VB/RB
1.0
#2
#1 Sets RBW, VBW, Sweep Time, Atten all to Auto.
• Set the manual/auto of resolution bandwidth, and auto (RBW, VBW and
SWP only) or all auto.
• Set Ratio of RBW to Span when RBW is Auto and Ratio Mode is “on”.
#2 Sets ratio of VBW to RBW when VBW is Auto.
• Set the manual/auto of video bandwidth, and auto (RBW, VBW
and SWP only) or all auto.
• Set the manual/auto of sweep time, and auto (RBW, VBW and SWP only) or
all auto.
