SECTION 4 SOFT-KEY MENU
4-22
(A<B)
A/B
(A>B)
A/B
(A<BG)
A/BG
(A>BG)
A/B
A/B,A/BG
return
Restart
Sweep Cntl
Continue
Stop
MS2665C Menu Tree (15/25)
Panel Key
Top menu Lower menues
#1
• Simultaneously display two waveforms, namely Trace A and Trace B or Trace A and
Trace BG (peripheral spectrum containing Trace A). The large display is Main Trace
and the small one is Sub Trace; select which to display as Main Trace (or Sub Trace).
Sweep Control: Set Stop/Continuous/Restart for sweep and Stop/Write for Sub
Trace.
#1 Displays two traces A and B simultaneously at top and
bottom of screen. The trace-B display is the larger at
this time.
A,B
A/B,A/BG
*
Sweep
Control
Sub Trace
Write
Sub Trace
View
