Anritsu Spectrum Master MS2721B User Manual

Chapter 2 — Instrument Overview 2-11 Test Panel Connectors
MS272xB + MS8911B UG PN: 10580-00175 Rev. N 2-13
2-11 Test Panel Connectors
The test panel connectors are shown in Figure 2-10, Figure 2-12, and Figure 2-11 and are
described in the text that follows.
MS2721B
Figure 2-10. Test Panel Connectors for MS2721B
External
Power
USB Interface
Mini-B
USB Interface
Type-A
Headset
Jack
Tracking
Generator
Output
Compact Flash
Socket
Fan Exhaust Port
External
Trigger
In
External
Reference
In
RF
In
GPS
Antenna
Connector
LAN
Connection
