Anritsu Spectrum Master MS2721B - MS2723 B and MS2724 B

2-11 Test Panel Connectors Chapter 2 — Instrument Overview
2-14 PN: 10580-00175 Rev. N MS272xB + MS8911B UG
MS2723B and MS2724B
Figure 2-11. Test Panel Connectors for MS2723B and MS2724B
External
Power
USB Interface
Mini-B
USB Interface
Type-A
Headset
Jack
Compact Flash
Socket
External
Trigger In
Fan
Exhaust
Port
RF
In
External
Reference
In
GPS
Antenna
Connector
LAN
Connection
IF
Out
