Chapter 6 — System Operation 6-3 System Menu
MS272xB + MS8911B UG PN: 10580-00175 Rev. N 6-3
System Options Menu
Key Sequence: Shift, System (8) > System Options
Date & Time: Press this submenu key to display a dialog box for setting the
current date and time. Use the submenu keys or the Left/Right arrow keys to
select the field to be modified. Use the keypad, the Up/Down arrow keys, or
the rotary knob to select the date and time. Press Enter to accept the
changes, or press the Esc key to return to normal operation without changing
anything.
Ethernet Config: Press this submenu key to display the Ethernet submenu
and to open the Ethernet Editor dialog box to set the IP address of the
instrument. For details, refer to section “Ethernet Configuration” on page C-1
in Appendix C, “LAN and DHCP”.
Language: Press this submenu key to open a list box and select a built-in
language for the Spectrum Master displays. The languages that are currently
available are: English, French, German, Spanish, Japanese, Chinese,
Korean, and Italian. In addition, a custom language may be selected if it has
been defined by using Master Software Tools and loaded into the
Spectrum Master. Two custom languages may be loaded into the instrument
via Master Software Tools. If a mode does not have language translations
available, then English is the default language. Press Enter to accept the
change, or press the Esc key to return to normal operation without changes.
In addition, any existing language (except English) may be edited for a better
local translation.
Note: A Factory Default reset (Esc+On) will overwrite any custom settings
within the Spectrum Master and will require that you reload the custom
language files via Master Software Tools. Refer to “Reset Menu” on page 6-6.
Description continued on next page.
Figure 6-3. System Options Menu (1 of 2)
Reset
System Options
Date
&
Time
Language
Name
Volume
Ethernet
Config
More
Brightness
To Next Page
