Main Menu Keys
The Spectrum Master menu-driven interface is easy to use and requires little training. The
5 Main Menu keys are located below the measurement display. These 5 keys are used to list
function-specific menus in the active menu (submenu labels). These Main Menu keys vary in
function based on the selected mode of operation (Shift, Mode (9)). Refer to
“Mode Selector Menu” on page 2-6 for more information on changing the instrument mode.
Table 2-1 lists the Main Menu Key labels for each mode of instrument operation.
Submenu Keys
The 8 submenu keys are located to the right of the measurement display. They change
function depending upon the current mode and current menu selection. The current submenu
title is shown at the top of the active function block (submenu keys labels). Refer to Figure 2-2
on page 2-3.
Table 2-1. Mode-Dependent Main Menu Keys Located Below Measurement display
Mode Key 1 Key 2 Key 3 Key 4 Key 5
Spectrum Analyzer Freq Amplitude Span BW Marker
Interference
Analysis
Freq Amplitude BW Measurements Marker
Channel Scanner Scanner Amplitude Custom Scan Measurements
Tracking Generator Freq Amplitude Span BW Marker
Power Meter Freq Amplitude Average Limits
High Accuracy
Power Meter
Amplitude Average Zero/Cal Limit
GSM/GPRS/EDGE Freq Amplitude Setup Measurements Marker
W-CDMA/HSDPA Freq Amplitude Setup Measurements Marker
TD-SCDMA/HSDPA Freq Amplitude Setup Measurements
CDMA Freq Amplitude Setup Measurements Marker
EV-DO Freq Amplitude Setup Measurements Marker
Fixed WiMAX Freq Amplitude Setup Measurements
Mobile WiMAX Freq Amplitude Setup Measurements Marker
ISDB-T Frequency/
Level
Meas
Selection
Meas Setup Execute
Measure
Save Files
ISDB-T SFN Frequency/
Level
Meas Setup Execute
Measure
Save Files
DVB-T/H Frequency Amplitude Setup Measurements Marker
DVB-T/H SFN Frequency Amplitude Setup Measurements Marker
