Symphony I/O Mk II Panel Tour
Front Panel
1.
Headphone Output!
a.
1/4” TRS connection provides an
assignable stereo headphone output!
2.
Touc hscree n !
a.
Symphony I/Os front panel touchscreen
offers convenient access to every setting
b.
Routing and the low latency Mixer can only
be controlled in Symphony Control software
3.
Control Knob!
4.
Power Button"
Rear Panel
1.
Module Slot 1!
2.
Module Slot 2!
3.
Thunderbolt ports (Symphony Mk II Thunderbolt model only)!
4.
Option Card Slot!
5.
Word Clock I/O!
6.
AC Power"
Symphony I/O Mk II - User's Guide Page 7
