Settings Tabs
Once a peripheral is selected in the Devices sidebar, settings for that peripheral are
displayed in the Main area, under the tab selection. In the case of Symphony I/O,
settings are distributed amongst the following tabs:
•
Input - settings pertaining to I/O Module analog and Digital Inputs are displayed in
this tab.
•
Output - settings pertaining to I/O Module analog and Digital Outputs are displayed
in this tab.
•
Device Settings - miscellaneous peripheral settings such as front panel meter
assignment are displayed in this tab.
•
Routing - When Audio Interface Mode is set to Symphony PCI, the Routing tabs
display the inputs and outputs of the Symphony 64 card, where routing between
hardware and software is performed. While the Input, Output and Device Settings
tabs display peripheral settings, the Routing and Mixer tabs display Symphony 64
card settings. When the Routing or Mixer tabs are selected, a yellow “halo” in the
Devices sidebar indicates this by encircling the Symphony 64 card and the attached
peripherals.
•
System Setup - Global settings pertaining to the entire Symphony System, including
all Symphony 64 PCI cards and attached peripherals, are displayed in this tab. A
yellow “halo” in the Devices sidebar encircles all the devices belonging to the
system. Settings found in this tab include Clock Source, Sample Rate and Global
Meter characteristics.
!
