AT682/683 Users Manual
48
Insulation Resistance: Accuracy
量程
电压
电压
1
2
3
4
5
6
1V
100k~1M
1M~10M
10M~100M
100M~1G
1G~10G
10V
100k~1M
1M~10M
10M~100M
100M~1G
1G~10G
10G~100G
25V
250k~2.5M
2.5M~25M
25M~250M
250M~2.5G
2.5G~25G
25G~250G
50V
500k~5M
5M~50M
50M~500M
500M~5G
5G~50G
50G~500G
75V
750k~7.5M
7.5M~75M
75M~750M
750M~7.5G
7.5G~75G
75G~750G
100V
1M~10M
10M~100M
100M~1G
1G~10G
10G~100G
100G~1T
125V
1.25M~12.5M
12.5M~125M
125M~1.25G
1.25G~12.5G
12.5G~125G
125G~1.25T
250V
2.5M~25M
25M~250M
250M~2.5G
2.5G~25G
25G~250G
250G~2.5T
500V
5M~50M
50M~500M
500M~5G
5G~50G
50G~500G
500G~5T
750V
7.5M~75M
75M~750M
750M~7.5G
7.5G~75G
75G~750G
750G~7.5T
1000V
10M~100M
100M~1G
1G~10G
10G~100G
100G~1T
1T~10T
Display: Vacuum-Fluorescent-Display (4-Colors VFD) Size: 98x55mm
Output Voltage: -1.0VDC ~ -1000VDC programmable in 3 ranges
Voltage Accuracy: <10V 10% 10V ±1%
<100V 0.1V resolution
100V 1V resolution
Parameter: Insulation Resistance, Leakage Current, Peak and Comparator Result.
Resistance Range: 100k ~ 1T
Basic Accuracy: (@Slow Rate) <1G: 1% 1G: 3% 10G: 5%
Maximum Reading: Slow Rate: 9999 Medium and Fast: 1999
Maximum Charge Current: 30mA 5mA
Rate (App.): Fast: 55 readings/s Med.:25 readings/s Slow: 3 reading/s
Charge Time: 999.9s 0.1s resolution Accuracy: 0.5%
Sample Time: 999.9s 0.1s resolution Accuracy: 0.5%
Trigger: Internal, Manual (Remote) and External Trigger
Range: Auto and Manual 6 ranges.
Correction: Open Clear Zero
Comparator: 30 sets of record. Display and Output GD/NG.
Beep: GD, NG and OFF
Interfaces: Built-in Handler Interface.
Built-in RS232C Interface.
Program Language: SCPI
Environmental: MIL-T-28800D, Type 3, Class 5, Style E & F
Operating: 0C to 50C, stated accuracy <45% RH
