Profile save screen
Select No. You will then be returned to the Idle screen for the network connection type selected.
3.7. Setting loopback
* With front panel option only.
Using loopback is a good way to perform a quick check on the functionality of the unit and that your cabling is
correct. To put the WorldCast Equinox unit into loopback press the Menu key until the following screen is dis-
played: -
User configuration screen
Use the and keys to highlight Loopback Mode and press Ent. The Loopback Mode Setup menu will
now be displayed.
Loopback setup screen
Use the and keys to highlight Local Loop and press Ent. This will enable the local loopback – audio
present on the audio inputs (i.e. local XLR connectors) will be routed through the internal encoder and then
looped back into the decoder and then to the audio outputs (i.e. local XLR connectors).
Note: If you are using digital audio analog audio output will also still be available - as will the audio
monitoring headset on the front panel.
Whenever you want to cancel the loopback repeat the above instructions but choose Loop Off and press Ent.
Loopback Mode Setup
Use Enter To Select
Loop Off.
Local Loop
Remote Loop
Main Menu.
USER ISDN IP AUDIO
Algorithm Eapt-X16
Loopback Mode Off
Autosync On
Headphone Volume 10
Audio I/O Analogue
Dig O/P 48K
To Next Page
