10
4.6 SELECTION MENU
The Selection menu depends on the set implement type (see chapter 4.4.3 Machine type)
After switching on the device, you can use the arrow buttons and the "OK" button to move through the
menu. Each time the arrow buttons are pressed in the menu, you move one menu item up or down.
The following menu points are available:
Main display (seeding shaft)
Speed (only with MDD and UDW)
Settings (only with LF; refer to the LF operating manual for more information)
Calibration test (no calibration test with LF)
Emptying
Quantity (only with LF)
Hour overview
Area overview
Operating voltage
Calibrating the speed
Fan settings (only with PS and MDP and with hydraulic PS with fan monitoring set to "Speed")
Languages
With the OK button, you go to the respective menu points. Here, you can change the value using the
plus/minus buttons.
4.7 INITIAL OPERATION OF THE CONTROLLER WITHOUT
CONNECTED IMPLEMENT
The control module can also be operated for the first time without connected implement. However, the
"Motor not connected (...)" error message then appears.
This error message can be suppressed for 15 sec. by pressing the OK button, then it appears again. This
mainly serves for reading out the operating hours, hectare counter and various settings without having to
connect the control module to the implement.
5 FUNCTION DESCRIPTIONS
5.1 CALIBRATION TEST (GENERAL INFORMATION)
NOTE!
In addition to performing a calibration test (setting of the seeding shaft speed), this menu point
is also used to set the working width and the forward speed. The entered values are also used
to calculate the area (seeded area).
Procedure:
1. Go to the Calibration test menu point and press the OK button.
2. In the Settings menu point, you can select whether you want to perform
the calibration in kg/ha, grains/m² (with thousand grain weight and
germination capacity) or g/m².
