The GPSa sensor transmits the current vehicle speed to the control
box. The current speed is measured through the combination of a
GPS and a 3D acceleration sensor. As a result, the sensor reacts
extremely rapidly to changes in speed. Moreover, the sensor must
only be mounted horizontally on the implement (with the arrow in the
direction of travel).
Order number: 00410-2-180
Cable length: 5 m
Connection: 12-pin plug on the control box
Scope of delivery: 1 GPSa sensor, data sheet, mounting plate
incl. mounting material
The radar sensor measures the forward speed [km/h]. This is
displayed on the control box and the seed quantity is automatically
regulated by regulating the speed of the seeding shaft. As a result,
the desired seed quantity per hectare is always maintained, even if
the driven speed deviates slightly from the speed defined by the
calibration test.
The radar sensor works on almost any substrate (e.g. soil, sand,
pavement, etc.). There may be imprecision if there is of snow or thick
layers of ice, or when the on-board voltage drops below 9 V.
Order number: 00410-2-179
Connection: 1-pin plug on the control box
Scope of delivery: 1 radar sensor, 1 mounting plate, incl.
fastening material
Settings: see Point Chapter 8.7
Cable length: 5 m
Installation position: should be between the wheels. Refer to
Figure 8 for the orientation and mounting
dimensions (35° in the direction of travel or
opposite).
