Arcam A38 User Manual

E-16
A38 P38
Continuous power output (20Hz—20kHz at 0.5% THD), per channel
Both channels, 8Ω, 20Hz—20kHz 100W 100W
Single channel, 8Ω, 20Hz—20kHz 150W 150W
Both channels, 4Ω, 20Hz—20kHz 140W 140W
Single channel, 4Ω, at 1kHz 200W 200W
Harmonic distortion, 80% power, 8Ω at 1kHz 0.005% 0.005%
Inputs
Phono input (optional module):
Input sensitivity 2.7mV (MM); 270µV (MC)
Input impedance 47kΩ (MM); 300Ω (MC)
Signal/noise ratio (CCIR) –79dB (MM); –73dB (MC)
Overload margin 35dB
Line inputs:
Nominal sensitivity 250mV—2V 800mV (pre-amp. in)
Input impedance 10kΩ 10kΩ
THD+n (1kHz, 0dB signal, measured 20Hz to
20kHz unweighted)
–104dB –104dB
Power amplier input
Nominal sensitivity 800mV 800mV
Input impedance 22kΩ 22kΩ
Gain 31.5dB 31.5dB
Preamplier output
Nominal output level 700mV
Maximum output level 2.6V RMS
Output impedance <50Ω
Headphone output
Maximum output level into 600Ω 1.6V rms
Output impedance 4.7Ω
General
Mains voltage 115V or 230V 115V or 230V
Power consumption (maximum) 800VA 800VA
Power consumption (standby) 2 VA 2 VA
Dimensions W x D x H (including feet) 430 x 370 x 110mm 430 x 350 x 110mm
Weight (net) 9.3kg 9.5kg
Weight (packed) 12.2kg 12.5kg
Supplied accessories mains lead
CR90 remote control
4 x AAA batteries
mains lead
E&OE
NOTE: All specication values are typical unless otherwise stated.
Continual improvement policy
Arcam has a policy of continual improvement for its
products. is means that designs and specications
are subject to change without notice.
specications

Arcam A38 Specifications

General

Amplifier class	-
Audio output channels	- channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
Dynamic power per channel (8 Ohm)	105 W
AC (power) in	Yes
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Volume control	Digital
Connectivity technology	Wired
AC input voltage	230 V
Package weight	12500 g

Weight and Dimensions

Depth	370 mm
Width	430 mm
Height	110 mm
Weight	9500 g
