Arkel ArLine User Manual V1.24
5.3. Overview Arkel ArLine-S-COP
5.4. Overview Arkel ArLine-S-TP
1
2
3
4
6
5
7
8
9
1. Arkel ArLine-M (Main unit) connection
2. External alarm button connection
3. Connection of external yellow and green pictogram LEDs
4. Output for external alarm button and pictogram LEDs
5. Volume adjustment trimpot
6. External microphone connection
7. External speaker connection
8. Information LEDs
9. Mounting holes
10
9
1
7
8
6
4
3
2
5
1. Arkel ArLine-M (Main unit) connection
2. Dip switch (Identification)
3. Yellow pictogram and its LED
4. Green pictogram and its LED
5. Alarm button (Yellow)
6. Intercom button (White)
7. Volume adjustment trimpot
8. Microphone
9. Speaker
10. Information LEDs
Figure 3 Arkel ArLine-S-COP appearance
Figure 4 Arkel ArLine-S-TP
