11. LED Information
11.1. Arkel ArLine-M LED Information
There is available a 24V DC supply.
There is available a built-in 5V DC supply.
The device processor is operating normally.
There is no active alarm condition.
An alarm call is in progress.
An alarm communication is in progress.
Alarm filtering is active.
Via CANbus or (AFLT) input or multiple parallel inputs.
The GSM signal level is very good.
The GSM signal level is good (Enough).
GSM signal level is poor (Insufficient).
Intercom talk is taking place.
SIM card / network error.
GSM signal level error.
Battery failure.
Arkel ArLine-S-COP not detected error.
Dip-switch identity setting error.
The battery is inserted and the condition is appropriate.
The SIM card is not inserted.
PIN code not removed or subscription service failure.
The SIM card is inserted and the status is appropriate.
Programmable input 1 powered.
Programmable input 2 powered.
Programmable input 3 powered.
Programmable input 4 powered.
Programmable input 5 powered.
Programmable relay 1 is pulled.
Programmable relay 2 is pulled.
11.2. Arkel ArLine-S-COP LED Information
There is available an external 12 / 24V DC supply.
There is a built-in 5V DC supply.
The device processor is operating normally.
The alarm call is taking place.
Communication with the Arkel ArLine-M unit.
11.3. Arkel ArLine-S-TP LED Information
There is an external 12 / 24V DC supply.
There is a built-in 5V DC supply.
The device processor is operating normally.
Alarm talk is taking place / Intercom talk is taking place.
