Arkel ArLine User Manual V1.24
1. Safety Precautions
• This product is designed and manufactured for use in lifts only.
• This product should be operated only by personnel authorized and trained on lift.
• The personnel must comply with all applicable health and safety requirements and standards related to the product.
• This product and its related connections must only be located in the areas which are accessible to the lift but not
accessible to unauthorized persons.
• For proper operation of the product, the instructions given in this manual and the other relevant guidelines must be
followed.
• The device should be de-energized before the SIM card, the GSM antenna and the other connections are made.
• The product must be installed in a way that it is protected from the effects of the environment (Water, moisture,
excessive dust, high temperature, etc.) which may cause damage.
• The product must not be used where there is a risk of explosion and where chemicals are used to a large extent.
• In order to ensure that the remote alarm system is kept in operational condition without interruption, and to take
necessary measures in case of a malfunction; the lift maintenance company, the lift owner and the rescue
service/personnel must be aware of and fulfill their duties. (See also EN 81-28 and EN 13015).
• ARKEL assumes no responsibility for accidents, flaws or possible defects caused by the user's lack of information or
carelessness. The same condition applies to all modifications to the product, except for ARKEL approval.
• ARKEL reserves the right to make changes in the product and this manual for functional or commercial reasons.
2. General Information
• Arkel ArLine is a remote alarm system designed for lifts. It complies with EN 81-28, EN 81-20 and EN 81-70 standards.
In addition to the remote alarm system, it can also function as an intercom system as required in EN 81-20.
• When an alarm is initiated from inside the car or from other trapped areas in the well, two-way communication is
provided to the system via pre-defined telephone numbers. In intercom operation, two-way communication is provided
between the speech units.
• All settings of the Arkel ArLine system are made via the web-based ARKEL Cloud system.
• When Arkel ArLine, which is designed to be compatible with all control panels, is used with ARKEL lift control
systems, some information obtained from the lift control system can be tracked online on the ARKEL Cloud website.
The Arkel ArLine system consists of 4 different units:
3. Package Contents
• Arkel ArLine-M main unit
• 1 x Arkel ArLine-M (Built-in battery)
• 1 x external antenna (With 3m cable)
• Arkel ArLine-S-COP car alarm unit
• 1 x Arkel ArLine-S-COP
• Arkel ArLine-S-TP well alarm unit
• 2 x Arkel ArLine-S-TP (The number of units
is 2 in the normal package content. But it may
change according to the user’s request.)
• Arkel ArLine-S-INT intercom unit
• 1 x Arkel ArLine-S-INT (Optional)
Check the contents of the package. Please contact ARKEL or your supplier if any items are missing or faulty.
Main unit (With built-in GSM/GPRS module and battery)
Alarm unit without enclosure used in the car operating panel
Alarm unit with enclosure used in the well (Top of the car/under the car/in the pit)
Intercom unit used in machine room or lift control panel
