Arkel ArLine User Manual V1.24
4.2. Arkel ArLine-S-COP Technical Specifications
Inputs
Unit supply
PWR, GND
(BAT connector
is not used)
10-30VDC
Max. 120mA @ 24V DC
External alarm button input
ALB1, ALB2
8-30VDC, 5 mA
Insulated with double direction
optocoupler
External microphone input
MIC (+, -)
Capacitive microphone with 2 special
connectors
Outputs
Supply output for alarm button and
pictogram LEDs
COM+, COM-
10-30V DC
Max. 100mA
External green pictogram LED output
GRE.
10-30VDC Max. 50mA
Transistor - (GND) output Short-circuit
and overcurrent protection
External yellow pictogram LED output
YEL.
External speaker output
SPE
8R speaker with 2 special connectors
Communication
interface
Arkel ArLine-M interface
A, B
RS-485 serial connection
User interface
Sound level adjustment trimpot, Information LEDs
General
Dimensions
100 x 65 x 14,1 (Width x Length x Height)
Weight
40g
Operating temperature
+5 C° - +40 C°
IP code
IP00(Proper protection must be provided in the car operating
panel to meet the desired IP level. )
Box
None
4.3. Arkel ArLine-S-TP Technical Specifications
Inputs
Unit supply
PWR, GND
(BAT connector is not used)
10-30VDC
Max. 120mA @ 24V DC
Communication
interface
Arkel ArLine-M interface
A, B
RS-485 serial communication
User interface
Microphone, Speaker, Alarm button, Intercom button, 4-pin dip switch (Identification)
Volume adjustment trimpot, Yellow and green pictograms and LEDs, other information LEDs
General
Dimensions
73 x 141 x 24MM (Width x Length x Height)
Weight
250 g
Operating temperature
+5 C° - +40 C°
IP code
IP20
Box
Metal
4.4. Arkel ArLine-S-INT Technical Specifications
Inputs
Unit supply
PWR, GND
(BAT connection is not used.)
10-30VDC
Max. 120mA @ 24V DC
Communication
interface
Arkel ArLine-M interface
A, B
RS-485 serial communication
User interface
Microphone, Speaker, Intercom button, 4-pin dip switch (Identification), Volume adjustment
trimpot, Intercom information LED and other information LEDs
General
Dimensions
73 x 141 x 24MM (Width x Length x Height)
Weight
250 g
Operating temperature
+5 C° - +40 C°
IP code
IP20
Box
Metal
