4. Technical Specifications
4.1. Arkel ArLine-M Technical Specifications
Mobile
Frequency band
Quad-Band 850/900/1800/1900 MHz
RF output power
Class 4 for EGSM 850/900 MHz (2W/33dBm max.)
Class 1 for DCS 1800/1900 MHz (1W/30dBm max.)
Technology
2G (GSM), GPRS
SIM card slot
Nano SIM (4FF), 12.30 x 8.80 x 0.67 mm
Antenna connection
SMA (Female) connector
External antenna
GSM, 2-3 dBi, 50 ohm (With 3m cable)
Internal battery
Type
12V/1.2Ah maintenance-free dry battery
Connection
Built-in, with 2-pin special connector cable
Charging
13,6 VDC, max. 100 Ma (Max. ~ 12 hours)
Supply time (With fully charged battery)
Standby state ~ 3 hours, when there is alarm talk ~ 2
Inputs
Unit supply
100, 1000
16-30V DC
Max. 500mA @ 24V DC
Programmable inputs
IN1, IN2, IN3,
IN4, IN5
8-30V DC, 5 mA, Insulated with
double direction optocoupler
Outputs
Arkel ArLine-S supply outputs
Arkel ArLine-S
Supply (PWR,
GND)
10-30V DC, Max. 400 mA
Supply outputs for programmable inputs
INCOM (COM+,
COM-)
10-30V DC, Max. 200 mA
Programmable relay outputs
OUT1, OUT2
Max. 2A, Max. 230V AC
Max. 30V DC
Communication
interface
Speaker interface (Only compatible with
the Arkel ArLine units)
CAR, PIT, EXT,
FF
RS-485 serial communication
Lift control system interface (Only
compatible with ARKEL products)
CANBUS
CANbus serial communication
4-pin custom connector
User interface
1 button, Information LEDs
General
Dimensions
163,20 x 133,23 x 72,20 mm (Width x Length x
Weight
1.3 kg (Including battery)
Operating temperature
+5 C° - +40 C°
IP code
IP20
Box
Metal
