Chapter 5:
STANDARD 365-095-33577 Revision x.1 IPC4100 Release 1.0 Installation and Operation Guide
15
When connecting to an audio receiver, reference its installation instructions for directions on
connecting to baseband and digital (S/PDIF) audio ports.
Note: The VCR and TV receive their A/V signals from the currently selected input device on
the audio receiver. This is important when the subscriber has another A/V device such as a
DVD player, a secondary VCR, a CD player, or other electronic component. We recommend
connecting the TV to the monitor output so on-screen menus for the receiver can be
displayed. In many cases, the receivers themselves have interactive on-screen menus.
Connecting the home router
To connect the home router:
1. Connect the Ethernet cable you routed from the ONT to the WAN Ethernet port on the
home router.
2. Make sure the router is powered ON.
3. Enable Dynamic Host Configuration Protocol (DHCP) on the router. Follow the
instructions provided with the router.
Connecting homes with multiple existing cable drops
Some customer premises may have multiple coaxial inputs from one or more taps, typically
entering different locations in the home. For the PON, it is practical to have one connection
only per customer premises. You must use a splitter and cabling to connect any additional
drops to the ONT. The routing will depend on the layout of the home and customer
preference.
Connecting the home router – embedded MoCA ONT
To connect the home router:
1. Connect the coaxial cable you routed from the ONT to the coax/MoCA port on the home
router.
2. Make sure the router is powered ON.
3. Enable Dynamic Host Configuration Protocol (DHCP) on the router. Follow the
instructions provided with the router.
