STANDARD 365-095-33577 Revision x.1 IPC4100 Release 1.0 Installation and Operation Guide
16
Chapter 6
Reviewing the IPC4100 installation steps
1. Determine if you are connecting to one of the following:
a. High-Definition TV or monitor - Use the HDMI output. No other video connection
supports HDTV.
If the TV has no HDMI input but does have a DVI input, connect a DVI-to-HDMI
adapter or cable to the HDMI out connector on the IPC4100 set-top and the
DVI-HDTV connector on your TV.
b. Standard-Definition TV - Connect the composite video connector using a composite
(RCA phono) cable.
2. Determine if you are connecting the audio to a home theater receiver or directly to the
TV:
a. For an HDMI video connection, no additional audio connections to the TV are
required.
b. For a DVI video connection, additional audio connections to the TV are required.
c. If the receiver or TV has a digital audio (S/PDIF) input, use the Optical Audio (S/PDIF)
output. Otherwise, use the baseband left and right audio outputs.
3. Locate the cabling diagram(s) that best match your planned configuration.
4. Connect the audio and video cables as shown in the diagram you are using.
5. Determine if you are connecting to a data device. For installation details, refer to the
instructions included with the data device.
6. Connect the FiOS TV In terminal to the coaxial cable wall outlet.
7. Perform the operational check for the remote control. See Performing remote control
operational check (page 19).
8. Optimize the high-definition settings. See Optimizing the High Definition Settings (page
26).
