Chapter 9:
STANDARD 365-095-33577 Revision x.1 IPC4100 Release 1.0 Installation and Operation Guide
27
Figure 11: User Settings Screen
5. Use the remote control or the cursor keys on the front panel to navigate the on-screen
menus:
• Press the p and q keys to highlight the setting you wish to change.
• Press the u key to select an option.
• To exit the setting and move to another setting, press the p or q key.
• To exit the menu and save your settings, press the Power or Menu key.
6. If the User Setting screen does not display on the HDTV screen, the TV may not support
the default video output setting. Use the front panel display to adjust the settings as
described in There is no video on the TV screen in the Troubleshooting (page 84) section.
Settings Description
TV Type Allows you to specify the style of television connected to the set-top. Options
include 16:9, 4:3 LETTERBOX, and 4:3 PAN SCAN. By default, the 16:9 option is
selected. The options are used as follows:
16:9 designates that a widescreen television is connected to the set-top.
4:3 LETTERBOX designates that a standard screen television is connected to
the RCM set-top and that widescreen programs should be scaled to fit the
screen with black bars above and below the picture.
4:3 PAN SCAN designates that a standard screen television is connected to
the RCM set-top and that widescreen programs should be cropped so that
the picture fills the entire screen.
HDMI/YPbPr
OUTPUT
Allows you to specify the video output format of the RCM set-
or for all 1080p, 1080i, and 2160p.
Options include:
1080p24 — The RCM set-top will present programs in the High-Definition
1080p24 format (1920 x 1080 pixels).
1080p30 — The RCM set-top will present programs in the High-Definition
1080p30 format (1920 x 1080 pixels).
1080p60 — The RCM set-top will present programs in the High-Definition
1080p60 format (1920 x 1080 pixels).
1080i — Default option: The RCM set-top will present programs in the
High-Definition 1080i format (1920 x 1080 pixels).
2160p24 — The RCM set-top will present programs in the High-Definition
2160p24 format (3840 x 2160 pixels).
2160p30 — The RCM set-top will present programs in the High-Definition
2160p30 format (3840 x 2160 pixels).
2160p60 — The RCM set-top will present programs in the High-Definition
2160p60 format (3840 x 2160 pixels).
Some televisions may only support certain video formats. Please consult your
