Chapter 10:
STANDARD 365-095-33577 Revision x.1 IPC4100 Release 1.0 Installation and Operation Guide
57
Field Description
Audio Mute /
Video Mute
Indicates if any of the audio or video outputs have
been muted by the software, for example, selectable
output control.
Input Source  Input source for the audio and video, for example,
IB Tuner.
Audio Mode Indicates the Audio mode of the incoming digital
service. Valid values:
 N/A - the audio mode is not applicable to the
currently tuned stream
 Mono - Audio mode is monophonic
 Stereo - Audio mode is stereo
 Surround - Audio mode is surround sound
 5.1 - Audio mode is Dolby Digital 5.1 surround
sound
 7.1 - Audio mode is Dolby Digital 7.1
Audio Lock /
Video Lock
Audio Decode
Error Count
Video Decode
Error Count
Output Control
Analog Output
Format
Digital Output
Format
Input Source
Input Format Includes the aspect ratio (4:3 or 16:9), the screen pixel
size (nnnnXnnnn), pixel display (i for interlaced, p for
progressive), and frames per second (24, 25, 30, 60).
3D TV Mode
3D TV Format
Figure 15:
