Chapter 10:
STANDARD 365-095-33577 Revision x.1 IPC4100 Release 1.0 Installation and Operation Guide
80
Field Description
has lost lock since the last reboot.
Data Indicates whether data is being carried by the OOB and
EMM traffic, which is tracked separately:
Front Panel Description
ON OOB data detected within last 5
seconds
OFF OOB data not detected within last
5 seconds
EMM Data Indicates whether EMM data is being carried on the OOB
stream:
Front Panel Description
ON EMM data detected within last 5
seconds
OFF EMM data not detected within last
5 seconds
SNR When carrier lock has been established, displays an
estimate of the carrier signal-to-noise ratio in dB, with an
explanation:
GOOD — Good value
FAIR — Marginal signal level, check the signal
POOR — Unusable signal
INVALID — Invalid SNR value
EMM Provider ID Displays the conditional access stream for the IPC4100
series, in hexadecimal.
EMM PID Displays the packet identifier (PID) stream the IPC4100
series tunes to for EMM data, in hexadecimal.
Network PID Displays the network PID to which the IPC4100 is tuned to
receive network messages, in hexadecimal.
Signal Level/Received
Power
Indicates the estimated received power for that
frequency in dBmV.
Hunt Mode The hunt mode includes Hunted, None, Round Robin (RR),
Search (SRCH), Fixed Frequency (FIX), or EMM Provider ID
(EMM).
LKC The Last Known Carrier is the last valid OOB frequency
that receiver has successfully acquired. The carrier value
is displayed in MHz and ranges from 70 to 130 MHz, with
the specific values of: 75.25, 104.20, 72.75, 92.25, 98.25,
107.25, 107.40, 110.25, 116.25, and 103.75.
