Chapter 11:
STANDARD 365-095-33577 Revision x.1 IPC4100 Release 1.0 Installation and Operation Guide
88
There are black bars on all
four sides of the picture.
This may occur on a 4:3 TV if the 4:3 OVERRIDE
setting is OFF. To set 4:3 SD programming to fill the
screen, depending on the capabilities of the TV, set
4:3 OVERRIDE to 480i or 480p.
This may occur on a 16:9 TV if the active video for an
SD broadcast is in letterbox format. To confirm, wait
for a commercial or look for a graphic, such as a
network logo. If the commercial fills the screen from
top to bottom, or the graphic appears below the
active video, the program is being letterboxed by the
broadcaster. You can minimize this by activating the
zoom feature on the TV.
A broadcaster may include black bars on either side
of a widescreen broadcast. This is called a “hybrid”
aspect ratio and results in a black border surrounding
the video on a 4:3 TV. Because this is part of the
broadcast, the VMS cannot correct the video. You
may be able to minimize the border using the zoom
feature on the TV.
Colors do not appear
correctly.
Be sure to match up each signal to the same
Component (YPbPr) connection on the TV.
Otherwise, colors will not appear correctly on your
TV.
