LUBRICATION
47 AU103170 H5B
LUBRICATION/MAINTENANCE CHART
* - As Required
NOTE 1: Use Astec Moly HT grease. Clean each grease fitting before and after you lubricate the pivot point of bearing.
NOTE 2: Use lithium base grease. Clean each grease fitting before and after you lubricate the bearings.
NOTE 3: Use engine oil or chain and open gear lube.
FREQUENCY IN HOURS
P
A
G
E
N
U
M
B
E
R SERVICE POINTS
L
U
B
R
I
C
A
E
D
R
A
I
N
W
A
T
E
R
C
H
E
C
K
C
L
E
A
N
C
H
A
N
G
E
57 Hydraulic Filter Warning Lamp Illuminated *
69 Clutch Adjustment *
54 Air Filter Restriction Indicator 10
53 Engine Oil Level 10
57 Hydraulic Reservoir Fluid Level 10
66 Digging Chain Deflection 10
61 Hydra-Borer Oil Level (If Equipped) 10
49 Chassis Pivot (See Note 1) 10
49 Sheave Coupling (See Note 1) 10
49 Clutch Throwout Bearing (See Note 1) 10
49 Clutch Main Bearing (See Note1) 10
50 Trencher Drive Chain (See Note 3) 10
49 Headshaft Bearing (See Note 1) 10
49 Boom Pivot (See Note 1) 10
50 Boom Cylinder Pivot (See Note 1) 10
50 Plow Bearings (If Equipped) (See Note 2) 10
50 Backhoe (If Equipped) (See Note 1) 10
67 Parking Brake Adjustment 50
43 Tire Condition/Air Pressure 50
66 Trencher Drive Chain Deflection 50
54 Air Cleaner Dust Valve 50
To Next Page
