SPECIFICATIONS
AU103170 H5B 92
Split Flange Mounting Bolts
Size Newton metres Pound-Inches
5/16-18 20 to 27 180 to 240
3/8-16 27 to 34 240 to 300
7/16-14 47 to 61 420 to 540
Pound-Feet
1/2-13 74 to 88 55 to 65
5/8-11 190 to 203 140 to 150
O-Ring Face Seal End
O-Ring Boss End
Fitting or Lock Nut
Nom. SAE
Dash Size
Tube OD Thread Size
Newton
metres
Pound-Inch-
es
Thread Size
Newton
metres
Pound-Inch-
es
-4 6.4 mm
(1/4 inch)
9/16-18 23 to 26 204 to 228
-6 9.5 mm
(3/8 inch)
11/16-16 34 to 40 300 to 348 9/16-18 48 to 54 432 to 480
-8 12.7 mm
(1/2 inch)
13/16-16 52 to 57 456 to 504 3/4-16 70 to 78 612 to 684
Pound-Feet
-10 15.9 mm
(5/8 inch)
1-14 81 to 90 720 to 792 7/8-14 102 to 114 75 to 84
Pound-Feet
-12 19.0 mm
(3/4 inch)
1-3/16-12 117 to 128 86 to 94 1-1/16-12 142 to 160 105 to 117
-16 25.4 mm
(1.0 inch)
1-7/16-12 152 to 174 112 to 128 1-5/16-12 237 to 254 175 to 187
-20 31.8 mm
(1-1/4 inch)
1-11/16-12 179 to 201 132 to 148
-24 38.1 mm
(1-1/2 inch)
2-12 213 to 235 157 to 173
