Chapter 3 Analog Output Settings (ANALOG OUTPUT)
11
● Specifications（VG-878-A）
AUDIO
L/R
Output frequency
100 to 20 kHz (Sampling frequency: 48 kHz)
Output level
0 to 4000 mV
Connector
RCA x2
YPbPr
Resolution
HDTV, SDTV
Number of colors,
bit length
YPbPr - 8 bit each
Connector
RCA x3
VGA
DotCLK
5 to 165 MHz
Number of colors,
bit length
RGB - 8 bit each
Connector
Dsub x1
SCART
Resolution*1
NTSC-M/J/443, PAL-B/D/G/H/I/M/Nc
Number of colors,
bit length
YPbPr, RGB - 8 bit each
Connector
SCART x1
Added functions*1
Teletext, ClosedCaption, Vchip, Macrovision*2
CVBS
Y/C
Resolution*1
NTSC-M/J/443, PAL-B/D/G/H/I/M/Nc
Number of colors,
bit length
YPbPr - 8 bit each
Connector
CVBS (RCA) x1, Y/C (S-Video) x1
Added functions*1
Teletext, ClosedCaption, Vchip, Macrovision*2
*1 Parts of the TV option function and TV timing signal may not be supported on items other than VG-878-A.
*2 Macrovision function is available when a license is purchased.
