Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
91
4.3.5 Payload
* These settings are only for payload identification data. For the settings that directly affect transmission signals, refer to each
corresponding item.
* When the VM-1876-M5 is used, the payload settings cannot be configured when SD output is set.
OFF/ON
Enables payload identification data.
[VM-1876-M5]
0: OFF
Does not multiplex the Payload ID.
1: ON
Multiplexes the Payload ID.
[VM-1876-MB]
0: OFF
Does not multiplex the Payload ID.
1: Y ON
Multiplexes the Payload ID with the Y
stream.
2: C ON
Multiplexes the Payload ID with the C
stream.
3: Y/C ON
Multiplexes the Payload ID with the Y/C
stream.
When OFF, the Mode and subsequent settings are not displayed.
Mode
Determines the payload setting method.
0: Refer Program
Determines the payload setting values
depending on the SDI output data
settings.
* Byte 1 and lower are not displayed.
1: Manual
Sets the payload settings manually.
* Settings other than payload settings
are not reflected.
* SDI output settings become no longer
able to be configured.
2: Hex
Sets byte 1 to byte 4 of the payload with
hex settings
* SDI output settings become no longer
able to be configured.
The following are displayed when Mode = 1: Manual is set.
Transport
Sets the transport scan mode.
0: Interlace
1: Progressive
Sets the picture scan mode.
0: Interlace
1: Progressive
Picture Rate
Sets the frame rate.
0: 23.98 Hz
1: 24 Hz
2: 25 Hz
3: 29.97 Hz
4: 30 Hz
5: 50 Hz
6: 59.94 Hz
7: 60 Hz
8: 47.95 Hz
9: 48 Hz
Aspect Ratio
Sets the aspect ratio.
*The bits that can be set vary depending on the setting of byte 1.
0: 4:3
Aspect ratio 4:3
1: 16:9
Aspect ratio 16:9
To Next Page
