Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
153
4.6.8 Control method
Arbitrary program data set on the front panel of the VG master or with a connected remote box output.
《Distributed output settings》
Level 1
Level 2
Level 3
Setting item
Setting value
All
Output
Multi VGMode(* VG-876 and VG-879 only)
Sets the splitting method for each VG1 when
multiple VG units are synchronized.
0: Auto
Splits into 4 quarters when 1320 MHz is exceeded with the
dot clock. Splitting is not performed at 1320 MHz or less.
1: H2/V2Div
4 quarter panes
2: V4Div
4 panes vertical
3: V2Div
Displays with 2 vertical panes. (Synchronized output of two
VG units)
* For details on output, refer to “4.6.4 Image of splitting method when synchronizing 4 units” or “4.6.5 Image of splitting
method when synchronizing 2 units”.
When multiple units are synchronized, there are the following restrictions.
Item
Restriction
Scrolling
Pausing is not linked. Only the master stops, and the scroll
position for each slave is reset by canceling pause.
M-Blur
Random is not linked in order for each unit to generate a
random number.
Cursor
Linked cursor display is not possible.
List display
HDCP, EDID, DDC, CEC, etc. are not supported.
APDC
Not supported.
3D patterns
Not supported.
Sync on/off
Not linked.
HDCP on/off
Not linked.
AudioMute
on/off
Not linked.
Video level
operation
Not linked. Only the master level is changed.
* digiVideoLevel of the program data to send to the slave is
updated with the next program execution.
Audio level
operation
Not linked.
The patterns you added and registered yourself, such as
Image, OPT-USER, and SUBTITLE need to be registered and
set on the VG units including the master unit.
