4.2.6 DisplayPort configuration setting items
This section describes configuration settings for the DisplayPort unit.
Set these settings from MENU > Configuration.
Level 1
Level 2
Level 3
Setting item
Setting value
Configuration
DP
Select Function
Function
0: Audio
1: MST
・ Audio
Uses the audio output function. MST is not supported when this function is
used.
・ MST
Uses the Multi-Stream Transport (MST) function. The audio output function is
not supported when this function is used.
* After selecting the function, save the configuration data with the SAVE key
and restart the VG. The selected function will be enabled after the restart.
Analysis Port
* Select the port to use for DP analysis.
0: DP1
1: DP2
2: DP3
3: DP4
4: DP5
5: DP6
6: DP7
7: DP8
Link Set Mode
0: refer Program
Follows the program setting.
1: Auto
Output always follows DPCD of
the sink device.
2: Manual
Output always follows the link
rate and lane count set in the
Configuration menu.
