Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
71
4.2.7 DP Analysis setting items
Set the DP Analysis settings.
Set these settings from MENU > DP Analysis.
I/F Check
* Performs a
simple checks of
the DisplayPort
interface.
Page = 1 (VG-876
and VG-879 only)
Performs link training with each press.
The link rate and lane count when link training is executed
follow the setting values in the DisplayPort Output Settings
menu.
Sets the power save mode setting for the connected
device. (*1)
Turns Audio MUTE on/off. (*2)
Enters the DisplayPort Output Settings menu. (*3)
Page = 2 (VG-876
and VG-879 only)
Restores the pattern of the currently selected program.
Displays the DisplayPort display screen GUI (refer to
“10.4.4 Displaying DisplayPort Setting Information”).
Reads the EDID of the connected device. This is the
same as the normal EDID Read.
Enters the DisplayPort Output Settings menu. (*3)
Training Pattern
* This is a mode
for outputting any
training pattern to
use for the
consistency check
of the DisplayPort
interface.
Pattern Select
Sets the pattern.
0: TPS1 (D10.2)
Outputs Training Pattern Sequence 1 (D10.2 test
pattern).
1: TPS2
Outputs Training Pattern Sequence 2.
2: Symbol Error Rate
Outputs Symbol Error Rate Measurement Pattern.
(This outputs only and does not measure the error
rate.)
3: PRBS7
Outputs PRBS7 Pattern.
4: TPS3
Outputs Training Pattern Sequence 3.
5: 80 bit Custom
Outputs 80bit custom pattern.
6: CP2520
Outputs HBR2 Compliance EYE pattern (CP2520).
Link Rate
Sets the link rate.
0: RBR (1.62 Gbps)
1: HBR (2.7 Gbps)
2: HBR2 (5.4 Gbps)
Lane Count
Sets the number of output lanes.
0: 1 lane
1: 2 lane
2: 4 lane
Voltage Swing
Sets the voltage swing level (differential motion level).
* The setting range differs depending on the pre-emphasis.
0: 0.4 V
1: 0.6V
2: 0.8V
3: 1.2V
Pre-emphasis
* The setting range differs depending on the voltage swing.
0: 0 db
1: 3.5 db
2: 6.0 db
3: 9.5 db
To Next Page
